OzSpy IP 25ch 8MP CCTV NVR 100MBS and P2P Remote View
This NVR boasts great quality, a three year warranty, up to 8MP recording. Connect this with you favourite OzSpy IP camera and you have a great system.
This NVR does not have PoE, so a PoE switch is required to power the cameras, or the cameras need to be powered at the camera.
Did you know that OzSpy recorders have a website login, this means you can check your cameras from anywhere you have a web browser. You can access our systems directly, via laptop, PC, mobile phone, and tablet giving our recorders the most options for remote view, and it’s simple to set up.
NVR Features
4K 8MP resolution
Motion detection
Push notifications on motion
Remote view
2 way audio
Audio
Onvif for compatibility with most Cameras
No PoE
IP
3 year warranty
12v DC
Works with:
OzSpy IP Cameras
HikVision Cameras
Dahua Cameras
Onvif Cameras
Specifications
System
Main Processor ARM Cortex A7 Processor
Operating System Embedded LINUX
Video
Input 25CH (4096×2160, 2592×1944, 2048×1536, 1920×1080, 1280×960, 1280×720, etc)
Output 1 VGA, 1 HD
Audio
Input 1 Port RCA
Output 1 Port RCA(Linear, 1kΩ)
Audio Bit Rate 64kbps
Audio Compression standard G711u, G711a
Alarm
Sensor Input NO
Output NO
Motion Detection25 Channel, MD Zones: 396 (22 × 18)
Trigger EventsRecording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output
Display
HD Output 1Resolution:4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Resolution:1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Display Split 25CHxD1/16CHxD1/9CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4k/1CHx12MP
Digital Zoom YES
OSD Camera Title, Time, Recording, Motion Detection
Recording
Video Compression H265/H264/H265+/H264+
Resolution4k(4096×2160),5MP(2592×1944),4MP(2688×1520),3MP(2048×1536),1080P(1920×1080),960P(1280×960),720P(1280×720),D1 (720×576/720×480)
Record Rate PAL :4k@12×25fp,5MP@20×25fp,4MP@25x25fp,3MP@25×25fp,1080P@25×25fp, 960P@25×25fp,720P@25×25fp, D1@25×25fp
NTSC: 4k@12×30fp,5MP@20×30fp,4MP@25×30fp,3MP@25×30fp,1080P@25×30fp, 960P@25×30fp, 720P@25×30fp, D1@25×30fp
Record Mode Manual\Timer\Motion Detection
Playback & Backup
Local Sync Playback 1CH 4K@30fps, 1CH 5MP@30fps,2CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps
Decode Capability 1CH 4K(3840×2160)@30fps
Remote Sync Playback YES
Search Mode ALL, Channel, Manual, Time, Date, Motion Detection
Playback Functions Play, Pause, Stop, Fast Play, Digital Zoom
Backup ModeUSB Device/Network
Network
Interface1 RJ45 10M/100/1000M Adaptive Ethernet Interface
Incoming Bandwidth 100MB
Network Functions TCP/CP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP, p2p
Onvif Version Support Onvif 2.4
Web Browser IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
CMS Software Support Windows 7/ Windows 8/Windows 10
Cloud Support(P2P) Yes
Smart Phone iPhone, iPad, Android, Android Pad
Storage
Interface Type 2 SATA Interface
Capacity Up to 16TB capacity
General
Language Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Farisa
German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek
USB Interface2 USB 2.0 Interfaces
RS485/
Power Supply DC12V/4A
Working Environment -10~55℃/10~90%
Dimension(W×D×H) 310*295*46(mm)
Weight 3.5KG (without HDD)
NVR Recorder Manual
➲Download Manual Here
