9ch 5MP CCTV Mini NVR 60MBS and P2P Remote View

$299.95

The OzSpy 9ch 5MP CCTV NVR with 60MBS and P2P Remote View is a great and easy to configure NVR. Accepting HikVision Dahua and Onvif cameras this NVR covers all the bases.

In stock

OzSpy 9ch 5MP CCTV Mini NVR 60MBS and P2P Remote View

This NVR boasts great quality, a three year warranty, and up to 5MP recording. Connect this with you favourite OzSpy IP camera and you have a great system.

This NVR does not have PoE so cameras need to be powered at the camera, or use a PoE switch.

Did you know that OzSpy recorders have a website login, this means you can check your cameras from anywhere you have a web browser. You can access our systems directly, via laptop, PC, mobile phone, and tablet giving our recorders the most options for remote view, and it’s simple to set up.



Features

5MP resolution
Motion detection
Push notifications on motion
Remote view
Audio
Onvif for compatibility with most cameras
PoE
IP
12v DC
3 year warranty

Works with:

OzSpy IP Cameras
HikVision Cameras
Dahua Cameras
Onvif Cameras



Specifications

System
Main Processor ARM Cortex A7 Processor
Operating System Embedded LINUX

Video
Input 9CH (2592×1944, 2048×1536, 1920×1080, 1280×960, 1280×720, etc)
Output 1 VGA, 1 HD

Audio
Output 1 Port 3.5mm(Linear, 1kΩ)
Audio Bit Rate 64kbps
Audio Compression standard G711u, G711a, G726

Alarm
Sensor Input NO
Output NO
Motion Detection 9 Channel, MD Zones: 396 (22 × 18)
Trigger Events Recording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output

Display
HD Output1Resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Resolution:1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Display Split 9CHxD1/8CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP
Digital Zoom YES
OSD Camera Title, Time, Recording, Motion Detection

Recording
Video Compression H265/H264/H265+/H264+
Resolution 5MP(2592×1944),4MP(2688×1520),3MP(2048×1536),1080P(1920×1080),960P(1280×960),720P(1280×720),D1 (720×576/720×480)
Record Rate PAL :5MP@9×25fp,4MP@9x25fp,3MP@9×25fp,1080P@9×25fp, 960P@9×25fp,720P@9×25fp, D1@9×25fp
NTSC: 5MP@9×30fp,4MP@9×30fp,3MP@9×30fp,1080P@9×30fp, 960P@9×30fp, 720P@9×30fp, D1@9×30fp
Record Mode Manual\Timer\Motion Detection

Playback & Backup
Local Sync Playback 1CH 5MP@30fps, 1CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@20fps, 4CH 960P@30fps, 4CH 720P@30fps
Decode Capability 4CH 1080P@20fps
Remote Sync Playback YES
Search Mode ALL, Channel, Manual, Time, Date, Motion Detection
Playback Functions Play, Pause, Stop,  Fast Play, Digital Zoom
Backup Mode USB Device/Network

Network
Interface 1 RJ45 10M/100M Adaptive Ethernet Interface
Incoming Bandwidth 60MB
Network Functions TCP/CP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP, p2p
Onvif Version Support Onvif 2.4
Web Browser IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
CMS Software Support  Windows 7/ Windows 8/Windows 10
Cloud Support(P2P) Yes
Smart Phone iPhone, iPad, Android, Android Pad

Storage
Interface Type 1 SATA Interface
HDD Capacity Up to 8TB not included

General
Language Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Farisa
German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek
USB Interface2 USB 2.0 Interfaces
Power Supply DC12V/2A
Working Environment -10~55℃/10~90%
Dimension(W×D×H) 260*215*43(mm)
Weight 2.0KG (without HDD)



NVR Recorder Manual

Download Manual Here



Weight 0.883 kg
Dimensions 33 × 28.5 × 7.5 cm
Remote View

Yes

App Name(s)

BitVision

OS

Android, iPhone, Windows XP/ Vista or Above / Win 7/8/10/11, Mac os

Memory

Up to 8TB HDD

Resolution

5MP

Powered By

12v DC

Record Modes

Motion Detection, Still Shot, Video

Warranty Period

36 Months Standard Warranty
